Roofing and Facade
Rockwool Insulated Wall Panel
Zetmar provides international sourcing and supply coordination for Rockwool Insulated Wall Panel, supporting projects that require documented quality, dependable delivery and project-specific material selection.
Relevant selection details include Insulation Thickness (40-50-60-75-80-100-120-150 mm) and Insulation Density (90-100-110 120-130 kg/m3). Final grades, dimensions and supply conditions can be matched to the intended application and project requirements.
Request a QuoteOverview
Rock Wools are fibroid and open cell structured materials. Rockwool insulated roof panels are preferred option in buildings where acoustic insulation and high fire safety are required.
With these features, while providing fire safety in your buildings, they also provide the high heat and water insulation required.
Specifications
| Rockwool Insulated Wall Panel | |
|---|---|
| Product Group | Wall Panels |
| Product Details | Metal Sheet + Rockwool Insulant + Metal Sheet |
| Insulation Thickness | 40-50-60-75-80-100-120-150 mm |
| Insulation Density | 90-100-110 120-130 kg/m3 |
| Panel Width | 100-150-200-250-300 cm |
| Panel Length | 2 - 15 meters |
| Outer Sheet Thickness | 0,4 - 0,8 mm |
| Inner Sheet Thickness | 0,4 - 0,8 mm |
| Line Option | Standard, shallow fluted, deep fluted, sinusoidal wawe design |
| Screw Option | External or hidden |
| Colour Options | RAL (9002, 9006, 7042, 7016, 5010, 5015, 6018, 6029, 3009, 3011, 2004, 1028) |
| Thermal Conductivity | Depending on panel thickness, λ between 0,70 - 0,24 w/m2k (Acc. EN 14509) |
| Fire Performance | A2-S1;D0 (Acc. EN 13501-1) |
